Products We Offer



  Pipes : PP / HDPE / PVC /PVDF / PPR / PPH / Simona
  Sheets : PP / HDPE / PVC / PVDF / PPR / PPH / Nylon / Teflon / Delerene / HIP / Polycarbonate / ABS
  Ball Valve
  Non Return Valve
  Foot Valve
  Butterfly Valve
  Flow Indicator
  "Y" Type Strainer
  Pipe End
  Bend
  Tee
  Reducer
  Hose Nipple with Flange
(1 Piece Moulded)
  Rods
  Blind Flange
  Basket Strainer
  End Cap
  Nutt Bolt
  Scoop
  Impeller
  Quick Change Hose Couplings
  Damper Valves
  Pall Ring
  Spade



Pipes

Polyethylene (PE)

Polyethylene is a thermoplastic polymer consisting of long chains produced by combining the ingredient monomer ethylene. The ethylene actually converts to ethane as it takes its place in a polymer and straight sections of the polymer are the same structure as the simple chain hydrocarbons, e.g., propane, decane and other straight single-bonded carbon chains. As with any polymer, the structure of the resulting substance defies molecular description due to cross branching of the chains. HDPE (High Density polyethylene) is defined by a density of greater or equal to 0.941 g/cm3. HDPE has a low degree of branching and stronger intermolecular forces and tensile strength.

Polypropylene (PP)

Polypropylene (PP) is a thermoplastic from the polyolefin group. It is a semi-rigid, translucent polymer with good toughness and weather resistance properties, low water absorption and is easily moulded to desired shapes. PP is a largely non-polar, partially crystalline thermoplastic with a crystallinity of 60 to 70% and a density of 0.90 to 3 0.91 g/cm which is amongst the lowest for all plastics.

It is generally available in three advanced forms:

PP Homopolymer (PP-H): Produced by a continous chain of polypropylene units which results in a high stiffness material. Advanced homopolymer types like beta nucleated PP, are used to make piping systems and sheets.

PP Copolymer (PP-C): Produced by adding 4-15% ethylene to the polypropylene gives much improved impact strength and considerably lowers the brittle point to below normal service temperatures i.e. -15°C to -20°C.

PP Random Copolymer (PP-R): Random copolymer polypropylene is a clear, semi-crystalline polymer which exhibits high stiffness, better impact strength and good electrical insulation properties. Other options in PP include fire retardant and electro-conductive grades. PP can also be UV stabilized.

Polyvinylidene Flouride (PVDF)


Polyvinylidene Fluoride (PVDF), the homopolymer of 1, 1-difluoroethylene, is a tough engineering thermoplastic that offers a unique balance of performance properties. The unique structure of alternating units of methylene and difluoromethylene, create a polymer with high crystallinity combined with a high polarity, resulting in a sharp melting point. It has the characteristic stability of fluoropolymers while retaining the properties of a conventional thermoplastic material. KYNAR FLEX ® resins are a series of PVDF based copolymers, similar to KYNAR ® homopolymer resins in purity and chemical resistance, but having additional chemical compatibility in high pH solutions, increased impact strength at ambient and low temperatures, and increased clarity.
