HDPE Pall Rings |
| |
|
| |
 |
Our organization is a prominent supplier of a comprehensive range of HDPE Pall Ring. This range can be availed from us at the most legit market prices in surplus. Widely demanded in the international arena, our range is a quality products and fulfill the requirements of the customers easily.
Following are applications of this range ...
- Suitable for acidic alkaline media
- With traces of solvents up to 70 degree Celsius
- Size: 16, 25, 38, 50, 76mm
- Diameter: 5/8", 1", 1.5", 2", 3"
- Usage: As tower packing
Features of this range are ...
- Made from virgin HDPE
- Optimum perfection in dimensions
- Sturdy construction
- Resistant to chemical applications
|
|
| |
|
| |
CPVC Pall Rings |
| |
|
| |
 |
We are one of the leading suppliers of a comprehensive range of Pall Ring CPVC. The offered range is the result of the post chlorination of PVC. Customers can easily chose from the wide variety of sizes and specifications in this range. Widely appreciated for its dimensional accuracy and optimum quality, the ring range is a distinct product of ours.
Features
- Economical
- Versatile
- Good capacity
- Low pressure drop
- Versatile standard packing
- Lower sensitivity to liquid and vapor
Applications
- Used in deep beds application
- Absorption
- Scrubbing
- Stripping service
Specifications
- Sizes: 16x16x1, 25x25x1.2, 38x38x1.4, 50x50x1.5, 76x76x2.6
- Surface m2/m3: 60, 210, 140, 100, 73
- Free Vol.%-91, 90, 89, 90, 92
- Weight kg/m3: 41, 82, 54, 51, 58
|
|
| |
|
| |
PVDF Pall Rings |
| |
|
| |
 |
Owing to the expertise of our professionals we are able to offer to them some of the most comprehensive and qualitative Pall Ring PVDF. The offered range has been designed in complete compliance to the standards of the industry. Extensively used across different industrial sectors, this product is perfect in packaging solutions.
Specifications of this range are as follows ...
- Size from 16mm to 76 mm
- Min piece density 171000 to 1765 pcs/m3
- Void age from 93.1% to 70.9%
- Surface area from min 344.2 to 73.2 m2/m3
|
|
| |
|
| |
PP Pall Rings |
| |
|
| |
 |
Our firm offers to its coveted customers a comprehensive range of PP Pall Ring. The offered range has been designed with utmost perfection and in accurate dimensions. Customers are offered this ring range at the most comprehensive and market leading whole sale prices.
Properties of this product are as follows ...
- High void ratio
- Low pressure drop
- Low specific weight
- High mass transfer efficiency
Types of thermoplastics included ...
- Polyethylene (PE)
- Polypropylene (PP)
- Reinforced polypropylene (RPP)
- Polyvinyl chloride (PVC)
- Chloride polyvinyl chloride (CPVC)
- Polyvinylidene fluoride (PVDF)
Common Applications ...
- Alkali industry
- Coal gas industry
- Environmental protection industry
|
|
| |
|
| |
PVC Pall Rings |
| |
|
| |
 |
Our organization has been widely engaged in the process of supplying of best quality PVC Pall Ring. Used in various applications at major chemical and processing industries. Available in thicknesses of 0.2mm to 1.5mm, the availability depends on the size of the pall rings. We offer this range in compliance to the standards of AISI SS 316/316L, AISI SS 304/304L, CS, SS (410, 430 and 202). This ring range has been specially fabricated out of best quality Copper, Inconel, Titanium and other alloy steels.
Following are the major specifications of this range ...
- Level of chlorine is increased from 56-57% to 74%
- CPVC resins contain 63 to 69% chlorine
- Maximum operating temperature of CPVC 200°F
Similar to ...
- Glitsch
- Koch glitsch
- Lanpac
- Sulzer Pall ring
Sizes
mm |
Surface
m2/m3 |
Free Vol.
% |
Number
per m3 |
Weight
kg/m3 |
| 16*16*1 25*25*1.2 38*38*1.4 50*50*1.5 76*76*2.6 |
260, 210, 140, 100, 73 |
91, 90, 89, 90, 92 |
230000, 53500, 13500, 6300, 1930 |
141, 82, 54, 51, 58 |
|
|
| |
|
|
